Rectangular Multilayer Piezo Actuators PTJ200 series Rectangular Multilayer Piezo Actuators

Product Introduction

Model: PTJ200 series
Brand: PANT
Material: piezoelectric ceramics
Shape: Rectangular and Square
Certifications: CE, RoHS, SGS ISO9001
Working voltage: -20 to 200V DC
Operating temperature range: 20 to 120℃
Wire lead: red is electrode (+), and black is cathode (-)
Recommended preload for dynamic operation: 15MPa
Maximum preload for constant force: 20MPa

Product Description

                                 <span><strong>Features</strong></span>

 <p> <span><img src="https://szutl.net/uploads/202607/17/ab91846c37e03012.webp" class=" lazyimg"/></span><span><span>Compact size</span></span>

Accurate positioning in nm

High-speed response in ms
Largeblockingforce

High energyconversion efficiency, low power consumption and no electromagnetic noise
Easy to be controlled by voltage

Scope of applications

Precision mechanics and mechanical engineering
Life sciences,Medicine and Biology
Pneumatic&Hydraulic valves
Nano positioning/high-speed switching
Active and Adaptive optics

Dimensions

Specification

Model	Dimensions	Nominal displacement	Blocking force	Stiffness	Electrical capacitance	Resonance Frequency
A×B×H [mm]	[μm@200V]	[N@200V]	[N/μm]	[μF]	[kHz]
±0.05	±10%			±20%	±20%
PTJ2000303051	3×3×6	5	330	66	0.11	250
PTJ2000303101	3×3×10	10	330	33	0.25	150
PTJ2000505051	5×5×6	5	900	180	0.35	250
PTJ2000505101	5×5×10	10	900	90	0.55	150
PTJ2000505121	5×5×12	12	900	75	0.57	125
PTJ2000505201	5×5×18	20	900	45	0.9	83
PTJ2000505301	5×5×28	30	900	30	1.5	53
PTJ2000505302	5×5×30	30	900	30	1.5	50
PTJ2000505401	5×5×36	40	900	23	1.8	42
PTJ2000505402	5×5×35	40	900	23	1.8	43
PTJ2000707101	7×7×10	10	1800	180	1.0	150
PTJ2000707201	7×7×18	20	1800	90	1.9	83
PTJ2000707301	7×7×28	30	1800	60	3	53
PTJ2000707381	7×7×32	38	1800	47	3.2	47
PTJ2000707401	7×7×36	40	1800	45	3.8	42
PTJ2000707501	7×7×42	50	1800	36	4.5	36
PTJ2001010101	10×10×10	10	3600	360	2.0	150
PTJ2001010201	10×10×18	20	3600	180	3.5	83
PTJ2001010301	10×10×28	30	3600	120	6.0	53
PTJ2001010401	10×10×36	40	3600	90	7.0	42
PTJ2001414101	14×14×10	10	7200	720	3.5	150
PTJ2001414201	14×14×20	20	7200	360	6.5	75
PTJ2001414301	14×14×30	30	7200	240	9.5	50
PTJ2001414401	14×14×40	40	7200	180	13	37

* Customizeon request.

Materials performance data

                                <table> <tbody> <tr> <td> <strong><span>Key Technical Index</span></strong></td> <td> <strong><span>Unit</span></strong></td> <td> <strong><span>Value</span></strong></td> </tr>

Relative dielectric constantε_r3^T - 3500±20% Electromechanical coupling factor Kp - 70% Longitudinal piezoelectric strain coefficient d₃₃ 10^-12C/N ≥650 Piezoelectric voltage constantg₃₃ 10^-3Vm/N 17 Elastic flexible coefficient S₁₁^E 10^-12m²/N 14.3 Elastic flexible coefficient S₃₃^E 10^-12m²/N 18.5 Dielectric loss tgδ 10^-3 ≤1.5 MqualityfactorQm - 45 CurietemperatureT_C ℃ 240 Densityρ g/cm³ 7.9
