Products Details
| Model | LPB2270BS-HS-12-4.0-R |
| Rated Voltage | 12VDC |
| Operating Voltage | 3～16VDC |
| Current Consumption | ≤12mA |
| Test distance | 10cm |
| SPL | ≥95dB @10cm |
| Resonant Frequency | 4000±500Hz |
| Tone | Continuous sound |
| Operating Temperature | -40～ +85℃ |
| Storage Temperature | -40 ～ +90℃ |
| Weight | 2.8 g |
| Carton size | 60×36×36 cm |
| Quantity | 3000 pcs |
| Gross Weight | 16.28Kg |
FAQ
1. What is Piezo Buzzer LPB2270BS used for?
Piezo Buzzer LPB2270BS is widely used in directional lights, burglar alarm systems, and reversing radar applications for reliable sound indication.
2. Is Piezo Buzzer LPB2270BS suitable for automotive use?
Yes, Piezo Buzzer LPB2270BS is commonly used in reversing radar systems and vehicle safety warning applications.
3. Does Piezo Buzzer LPB2270BS support high temperature environments?
Yes, Piezo Buzzer LPB2270BS is designed with high temperature resistance for stable performance in harsh conditions.
4. What is the sound performance of LPB2270BS?
Piezo Buzzer LPB2270BS provides high sound pressure output for clear and effective alarm signaling.
5. What is the voltage range of Piezo Buzzer LPB2270BS?
Piezo Buzzer LPB2270BS supports a wide voltage range from 3V to 16V for flexible electronic integration.
6. What is the delivery time for LPB2270BS?
Piezo Buzzer LPB2270BS supports fast delivery within 7 - 21 days after order confirmation.
7. What is the monthly production capacity of LPB2270BS?
Piezo Buzzer LPB2270BS has a stable monthly supply capacity of around 50,000 units for OEM/ODM bulk orders.
